⌁ RHEL networking · Challenge 08

Cache the web.
Gate the LAN.

Workstations on the office LAN need controlled internet access through a caching proxy, but no proxy exists yet. Install Squid on this RHEL node, configure an allow rule for the LAN, enable the service, and open the firewall — then verify a client can reach the web through it.

PRX-0801 · squid-01 · forward proxy deployment

4objectives

15minute target

100points

Proxy setup

Challenge Lab 8 · Squid Web Proxy

Enter your name exactly as it should appear on your certificate.

Your lab runs entirely in this browser. No account is required.

Forward proxy assessment

Squid Web Proxy Challenge

TIME00:00

SCORE0/100

Mission brief

Stand up a LAN forward proxy

INTERMEDIATE

This RHEL node sits at the LAN edge. Install Squid, configure it to listen on 3128 and allow the 192.168.1.0/24 subnet, enable the service at boot, open the firewall, and verify a proxied request succeeds.

1
Install Squid
Install the squid package.
20 pts
2
Configure the proxy
Set the listen port and allow the LAN subnet.
30 pts
3
Enable & start the service
Enable Squid at boot and start it now.
25 pts
4
Open the firewall & verify
Allow the proxy port, then curl through it.
25 pts

Progress0 of 4 complete

Need a hint?Open setup guide

Install: sudo dnf install -y squid.

Configure: sudo tee /etc/squid/squid.conf <<'EOF' … EOF with http_port 3128, acl localnet src 192.168.1.0/24, and http_access allow localnet.

Enable & start: sudo systemctl enable --now squid.

Firewall: sudo firewall-cmd --permanent --add-service=squid then sudo firewall-cmd --reload.

Verify: curl -x http://localhost:3128 http://example.com.

Type help to see all supported commands.

squid-01 — proxy shell

ISOLATED · SIMULATED

  ____   _______        __
 |  _ \ / ___\\ \      / /
 | |_) | |    \ \ /\ / /
 |  _ <| |___  \ V  V /
 |_| \_\\____|  \_/\_/

RCW RHEL Proxy Practice Environment

Install and configure a Squid forward proxy. Enter help for available commands.

Proxy operational

Excellent work, Learner!

You installed Squid, configured a LAN allow rule on port 3128, enabled and started the service, opened the firewall, and verified a client request through the proxy.

Final score

100/ 100

PERFECT SCORE

Forward proxy live — LAN can browse via Squid

Objectives: 4 / 4
Completion time: 00:00
Commands entered: 4
